Devemed Micro Needle Holders
Devemed Periolux Luxators
Devemed Periolux Luxators
TIN-Periolux are designed to be easily inserted along the root surface and cut the periodontal ligament prior to extraction (Attention: no levering).
They feature a long, slender profile and sharp blades, which will minimize tissue trauma and preserve alveolar bone.
The TiN coating improves gliding in the periodontal gap due to its lower coefficient of friction and improves the durability of the blades. T
Available on 165mm
3.00 mm or 4.00 mm
Curved or Straight
Devemed Dev-os-system Set
The devemed dev-os-system is ideally suited for osseointegration. The toolbox (4400-00) offers plenty of space for micro-screws, pins and drills – the clear structure enables easy, direct holding of pins and screws.
Our dev-os QUADRO TITAN micro screws prevent the screw from spinning due to their screw head with a slightly conical quadro profile.
They also provide a better grip on the screwdriver, ensuring safe pick-up and placement. We offer dev-os QUADRO screwdriver blades and pilot drills to match.
The devemed twist handle (4311-00) is suitable for screwdriver blades, pin applicators and pin drivers.
Its shape allows comfortable handling: the silicone handle can be turned and the pressure point at the back is firm, making turning easy and safe.
Devemed Pilotdrill Ø 1.5 mm / 33 x 15 mm | dev-os-system
Product information: dev-os | Ø 1.5 mm / 33 x 15 mm | Pilotdrill | Stop | with dental fitting
The drill bit 4218-00 is used for pre-drilling for the dev-os QUADRO TITAN micro-screws with a diameter of Ø 1.8 mm.
The pilot drill has a diameter of Ø 1.5 mm, which is slightly smaller than the titanium screw, ensuring a secure hold in the jaw.
It is graduated (5-7-9-11-13 mm) and has a stop at 15 mm to prevent over-drilling.
The total length is 33 mm.
With standardized dental attachment.
Devemed Pilotdrill Ø 1.2 mm / 33 x 15 mm | dev-os-system
Product information: dev-os | Ø 1.2 mm / 33 x 15 mm | Pilotdrill | Stop | with dental fitting
The drill bit 4215-00 is used to perform pre-drilling for the dev-os QUADRO TITAN micro-screws with a diameter of Ø 1.5 mm.
The pilot drill has a diameter of Ø 1.2 mm, which is slightly smaller than the titanium screw, to ensure a secure hold in the jaw.
It is graduated (5-7-9-11-13 mm) and has a stop at 15 mm to prevent over-drilling.
The total length is 33 mm.
With standardized dental attachment.
Devemed Pilotdrill Ø 1.0 mm / 33 x 15 mm| dev-os-system
Product information: dev-os | Ø 1.0 mm / 33 x 15 mm | Pilotdrill | Stop | with dental fitting
The drill 4213-00 is used to perform pre-drilling for dev-os QUADRO TITAN micro-screws with a diameter of Ø 1.3 mm.
The pilot drill has a diameter of Ø 1.0 mm.
The diameter is slightly narrower than the titanium screw to ensure a secure hold in the jaw.
The drill is graduated (5-7-9-11-13 mm) and has a stop at 15 mm to prevent drilling too deep.
The total length is 33 mm.
With standardized dental attachment.
Devemed Pilotdrill Ø 0.7 mm / 40 x 7 mm | dev-os-system
Product information: dev-os | Ø 0.7 mm / 40 x 7 mm | Pilotdrill | Stop | with dental fitting
The pilot drill 4210-00 is used to perform pre-drilling for the dev-os QUADRO TITAN micro-screws with a diameter of Ø 1.0 mm.
The pilot drill has a diameter of Ø 0.7 mm - it is therefore slightly narrower than the titanium screw to ensure a secure hold in the jaw.
The drill has a stop at 7 mm to prevent drilling too deep.
The total length is 40 mm.
With standardized dental attachment.
Devemed Screwdriver Blade Short 30mm Ø 1.3 mm with Dental Fitting | dev-os-system
Devemed Screwdriver Blade Long 70mm 1.3 Ø with Dental Fitting | dev-os-system
Product information: This screwdriver blade offers you the optimal solution for implantology.
With a length of 70 mm, it is particularly long.
The QUADRO profile prevents the screw from slipping and ensures a secure grip.
This blade can be used for screw systems with diameters of Ø 1.3 mm, Ø 1.5 mm, and Ø 1.8 mm.
With dental attachment.
Devemed Screwdriver Blade Short 30mm Ø 1.0 with Dental Fitting | dev-os-system
Product information: The screwdriver blade for Ø 1.0 mm QUADRO TITAN micro-screws is available in a length of 30 mm.
The QUADRO profile ensures a reliable fixation and prevents the screw from slipping.
This blade is compatible with screw systems of Ø 1.0 mm diameter and enables precise work.
Without color marking, with dental attachment.
